easy to use fish finder
Professional 10-inch high power fish finder (1000-1500W) with 50/200kHz dual-frequency. Clear color LCD, customizable settings, and marine certification. Ideal for commercial fishing boats. Factory direct price.
Product Introduction
10 Inch 1000-1500W High Power Fish Finder | 50/200kHz Dual-Frequency Sonar
Product Overview
Designed for serious commercial fishing operations, the SAIYANG 10-inch High Power Fish Finder delivers 1000-1500W of adjustable transmission power for exceptional depth penetration and target separation in deep waters. Operating at dual frequencies of 50kHz (wide coverage for shallow to medium depths) and 200kHz (high-resolution detail for bottom structure and fish arches), this professional sonar system ensures you never miss a catch. Certified by the Register of Fishing Vessel of the People's Republic of China, it's built to withstand rigorous marine environments.
Key Features
- High-Contrast 10" Color Display: Daylight-viewable LCD screen provides crisp, clear echo presentations even under direct sunlight – ideal for outdoor marine use.
- Fully Adjustable Power Output (1000-1500W): Match your sonar's transmitting power to specific water depths and conditions, from coastal reefs to deep-sea fishing grounds.
- Dual-Frequency 50/200kHz Operation: Use 50kHz for wide beam angle and maximum depth coverage, or switch to 200kHz for precise target tracking and bottom contour mapping.
- User-Friendly Marine Controls: Easily adjust Gain, TVG curve, Transmit Rate, and Pulse Width to fine-tune performance for different fishing tactics (trawling, longlining, etc.).
- Rugged & Certified Reliability: Holds official certificate from China's fishing vessel registry; built with isolated power supply and PWM control for noise-free, stable operation on commercial boats.
- Customizable Display Settings: Multiple user-selectable operating functions including gain control, TVG graph, transmit rate, and pulse width for tailored fishing operations.
Product Details
The SAIYANG FP1021S is a high-power professional fish finder specifically engineered for commercial fishing vessels. Its 1000-1500W adjustable power output allows operators to optimize sonar performance based on water depth, salinity, and bottom composition. The dual-frequency transducer (sold separately or as a kit) provides versatility: use 50kHz for broad coverage when searching for schools, then switch to 200kHz for detailed bottom structure and individual fish arch identification.
This model features a full isolated power supply with PWM control, ensuring clean, noise-free operation even in electrically noisy marine environments. The daylight-viewable 10-inch color LCD screen delivers sharp echo displays with multiple color palettes for easy interpretation. With certification from China's fishing vessel registry, this unit meets rigorous standards for reliability and durability at sea.
Frequently Asked Questions (FAQ)
50kHz offers a wider beam angle (approx. 45°), covering more water volume – best for locating schools in mid-depths. 200kHz delivers a narrower beam (approx. 15°) for high-definition views of individual fish and bottom structure.
While it's optimized for commercial vessels, any boat with sufficient power supply (24V DC) and transducer mount can benefit from its advanced features. Adjustable power lets you lower output for shallower waters.
Please contact our sales team to confirm transducer compatibility. We offer matching OEM or OVA marine rubber transducers for this model. The fish finder is compatible with most 50/200kHz transducers.
With 1500W of power, depth capability depends on bottom conditions and salinity. Typically, it can reach over 500m in freshwater and 500m in saltwater. Contact us for specific charts.
Yes, SAIYANG offers a standard one year limited warranty on the fish finder main unit. Extended coverage options are available for commercial fleets.
You Might Also Like
Interested in bulk orders or customized labeling? Get a wholesale price quote for the SAIYANG 10-inch high power fish finder (1000-1500W).
Request a Quote →Or contact us directly: Email: sales@saiyangmarine.com | Tel/WhatsApp: +86 89129287
Technical parameters：
|
Model |
FP1021S |
|
TX Frequency |
50&200KHz |
|
Output Power |
1000W-1500W |
|
TXRate |
0.12~3.0ms |
|
Accuracy |
0.1m |
|
Sensitivity |
-95dBm |
|
Alarm |
Depth,Voltage,Temperature |
|
Language |
Simplified Chinese, English, Traditional Chinese |
|
Display Unit |
|
|
Display Mode |
Dual frequency,Single frequency (high or low freq.), A-scope, Zoom(high or low freq.) |
|
Expansion Mode |
Auto Expansion,Manual Zoom,Bottom Lock |
|
TXRate |
7 steps(stop,1/8,1/4,1/2,1/1,2/1,3/1) |
|
Color |
Echo color:5 color schemes Background color：black, blue |
|
Interface |
|
|
Input data |
IEC61162-1(NMEA0183)RMC, GLL |
|
Output data |
IEC61162-1(NMEA0183)DPT, DBT(After GLL and RMC Input) |
|
Serial port to print |
Suitable for printer DPU-414 |
|
Power Supply |
DC 24V(11-35V) |
|
Environmental |
|
|
Operating temperature |
-10℃~+40℃ Compliance with IEC60945 standard |
|
Working humidity |
10~90% |
