Fish Finder And Transducer

OVA Professional Fish Finder with 12-Inch Sunlight-Readable Vertical Display – 1500-3000W Output for Commercial Fishing Boats

For professional fishing boat captains who need to process sonar data at a glance, this OVA fish finder features a 12-inch vertical display readable in direct sunlight. The upright screen orientation shows more water column history than square displays, helping you spot fish school movement patterns. With 1500-3000W output power and flexible frequency support 50&200kHz), this system performs in both shallow and deep waters.

Designed for Professional Fishing Operations

12-inch vertical sunlight-readable display – The upright format displays more historical sonar data vertically, allowing you to see how fish schools moved through the water column over time. Sunlight-readable construction ensures visibility on open fishing bridges.

1000W output power – High transmit power penetrates deep water and maintains bottom lock in rough sea conditions. Suitable for offshore commercial fishing operations.

Dual-frequency display – View 50kHz and 200kHz returns simultaneously on the split screen. Identify fish schools more efficiently by comparing wide search beams with narrow detailed beams.

Multi-function knobs and dedicated buttons – Operate important functions without navigating menus. Tactile controls work with wet or gloved hands on a moving fishing boat.

Frequency Flexibility

Flexibly support 45-200KHz frequency range for use in different shallow and deep waters. Select the optimal frequency for your current fishing ground:

Low frequencies – Wide beam width for shallow water search and large school detection

High frequencies – Narrow beam for deep water bottom detail and individual fish arch separation

Technical Specifications

Display and Expansion Modes

Auto Expansion – Automatically adjusts display scale to keep bottom in view as depth changes. No manual range adjustments during normal operation.

Manual Zoom – Select any depth range to magnify. Examine bottom structure or mid-water fish schools in detail.

Bottom Lock – Locks the display to follow the bottom contour. Shows fish and structure immediately above the seafloor – critical for bottom fishing species.

Data Integration

Input data (IEC61162-1 NMEA0183 RMC) – Receives GPS position and speed data from your chart plotter for accurate sonar processing relative to vessel movement.

Output data (IEC61162-1 NMEA0183 DPT, DBT, GLL, MTW) – Feeds depth, water temperature, and position data to autopilots, radar systems, and network displays.

Serial port for printing (DPU-414 compatible) – Print sonar screenshots and bottom profiles for fishing logs or captain's reports.

Alarms for Professional Operations

Depth alarm – Set minimum and maximum depth limits. Alarm sounds when vessel enters unsafe shallow water or leaves productive depth range.

Voltage alarm – Monitors vessel electrical system. Warns of low voltage before fish finder performance degrades.

Temperature alarm – Alert when water temperature enters target species range (tuna, salmon, etc.).

Included Transducer

This professional package includes a matching transducer optimized for the 1000W output power. Contact our sales team to confirm transducer type (hull mounting style, beam width options) for your specific vessel and fishing depths.

Technical parameters：
