Ship Navigation Radar
Saiyang SYRSB-1004 ship navigation radar: X-band, 4KW output, 36nm max range, 4° horizontal beamwidth. Ideal for yachts & fishing boats. Get NMEA0183/AIS integration & VGA split display. Inquire for wholesale price.
Product Introduction
10-inch 4KW Marine Navigation Radar for Fishing Boats | 36nm Range SYRSB-1004 - Saiyang
For captains of fishing boats and yachts needing reliable collision avoidance in coastal waters:Saiyang SYRSB-1004 provides a 36-nautical-mile range with a 4° horizontal beamwidth – detecting small targets like buoys and small boats where consumer-grade radars fail, while its 24V DC operation (10.2-40V range) simplifies retrofit on vessels with unstable power supplies.
Key Problems Solved
Dense target discrimination: 4° horizontal beamwidth separates close targets (e.g., channel markers near harbor entrances)
All-weather reliability: X-band (9410MHz) minimizes sea clutter interference compared to S-band in rainy conditions
Data integration: Native NMEA0183 & IEC61162-2 inputs for GPS, AIS, heading, and log data – no protocol converters needed
See further in coastal fog: 4KW transmit power + 36nm range
Spot small targets: 0.08us short pulse width for 0.125-1nm ranges (details objects like crab pot floats)
Connect to any plotter: VGA split port + dual-format AIS/GPS inputs
Power flexibility: Works on 12V to 36V DC systems (2.6A draw at 24V)
Target Application Matrix
| For Vessel Type | Primary Benefit | Key Spec Matched |
|---|---|---|
| Offshore fishing boats | Detecting semi-submerged logs/trawls at night | 0.8us pulse width @ 600Hz PRF |
| Coastal yachts | Collision avoidance with AIS targets | IEC61162_2 heading data sync |
| Commercial workboats | Dual-range monitoring (short + long pulse) | 0.08us and 0.8us selectable |
Antenna
| Parameter | Specification |
|---|---|
| Model | SYRSB-1004 |
| Length | 58 cm |
| Beam Width (Horizontal) | 4 degrees |
| Beam Width (Vertical) | 25 degrees |
| Rotation Speed | 24 RPM |
Transmitter
| Parameter | Specification |
|---|---|
| Frequency | 9410MHz ±30MHz (X-band) |
| Output Power | 4 kW |
Pulse Width & PRF by Range:
| Range (nm) | Pulse Width (µs) | PRF (Hz) |
|---|---|---|
| 0.125 / 0.25 / 0.5 / 0.75 / 1 | 0.08 | 2200 |
| 1.5 | 0.08 / 0.3 | 2200 / 1200 |
| 2 / 3 | 0.3 | 1200 |
| 4 / 6 / 12 / 16 / 24 / 32 / 36 / 48 / 64 | 0.8 | 600 |
Receiver
| Parameter | Specification |
|---|---|
| Microwave Front End | MIC |
| Noise Factor | 8 dB |
| Intermediate Frequency | 60 MHz |
| Bandwidth (0.08µs pulse) | 25 MHz |
| Bandwidth (0.3µs pulse) | 5 MHz |
Interfaces
| Data Type | Format |
|---|---|
| GPS | NMEA0183 / IEC61162-1 |
| AIS | IEC61162-2 |
| Heading (Gyro) | IEC61162-2 |
| Log (Speed) | IEC61162-1 |
| Split Display | VGA Port |
Power
| Parameter | Specification |
|---|---|
| Rated Voltage | DC 24V |
| Voltage Range | DC 10.2V – 40.0V |
| Operating Current | 2.6A (at 24V DC) |
